The JK20 vertical 5-axis CNC machining center makes its grand debut at EMO 2025!

When manufacturing precise and complex small parts, efficiency and quality are often the biggest challenges facing companies. To address this pain point, we’ve dedicated our efforts to developing the JK20 vertical 5-axis CNC machining center—an intelligent tool focused on multi-process machining of small impellers, medical implants, watches, and automotive parts. Leveraging its highly rigid machine structure and advanced five-axis simultaneous technology, the JK20 not only improves machining accuracy but also effectively shortens production cycles, helping companies seize an advantage in the fiercely competitive market.

Stable Machine Structure Ensures Machining Accuracy and Stability

The JK20 utilizes a one-piece casting bed design with meticulously optimized construction, achieving industry-leading stability. This one-piece casting bed not only effectively reduces mechanical vibration but also provides the machine with exceptional rigidity, ensuring excellent positioning accuracy and surface quality even under long-term, high-load, and high-speed machining conditions.

The machine’s moving beam Y-axis structure, combined with a highly rigid cradle base, further enhances the stability of its cutting performance. This combined design ensures the JK20 possesses exceptional cutting resistance and mechanical rigidity when machining complex curved surfaces and deep cavities, ensuring optimal quality in demanding machining environments.

Five-Axis Synchronization, High-Speed, High-Precision Machining Capabilities

The JK20′s core advantage lies in its powerful five-axis control system. Its C-axis boasts a maximum speed of 2000 rpm, enabling 360-degree positioning without blind spots, greatly enhancing machining flexibility. The machine’s three linear axes, X, Y, and Z, are equipped with precision scales, providing real-time position feedback. This improves tool positioning accuracy and repeatability, ensuring consistent machining of complex workpieces.

This five-axis simultaneous design not only shortens process steps and increases production efficiency, but also helps users enhance the overall geometric integrity of parts, reduce clamping times, and minimize positioning errors, making it the preferred choice for machining small, high-precision parts.

Multi-Process Integration Meets Diverse Manufacturing Needs

The JK20 supports deeply integrated multi-process machining, effectively unifying roughing and finishing, achieving multi-process integration. This not only significantly improves production efficiency but also significantly shortens delivery cycles, reducing errors and operational complexity caused by multiple workpiece clamping.

Furthermore, the machine’s flexible configuration allows customers to customize different tools and accessories based on their specific needs, enabling efficient cutting of a wide range of materials. Through its optimized dynamic control strategy, the JK20 ensures stability and reliability even under high-speed and high-load conditions, helping manufacturers continuously improve production capacity and processing quality.

Professional Intelligent Control for an Enhanced Operator Experience

The JK20 is equipped with an advanced CNC system compatible with mainstream industry programming languages and communication protocols. The user interface is simple and intuitive, allowing for rapid program import and secondary editing, lowering the programming barrier and shortening debugging cycles. Intelligent diagnostics monitor equipment status 24/7, providing timely warnings of anomalies, reducing the risk of downtime, and ensuring safe and efficient production operations.

The machine also supports remote maintenance and upgrades, facilitating subsequent technology upgrades and functional expansion, meeting the needs of continuous manufacturing process optimization and truly leading the future of intelligent manufacturing.

Application Cases and Industry Value

The JK20 vertical 5-axis CNC machining center has been proven in practical applications by customers across multiple industries, providing significant benefits in the following areas:

· Medical devices: Providing micron-level machining solutions for various high-precision implants, improving product safety and compatibility;

· Automotive parts: Meeting the demands for efficient, high-quality machining of complex parts such as engines and turbine blades;

· Watchmaking: Addressing the precision machining of micro-complex parts to create high-end timepieces;

· High-end manufacturing: Multi-faceted machining to meet the high standards of aerospace and industrial equipment manufacturing.

We also offer customized automation solutions for the metalworking industry. Based on high-end CNC milling machines and CNC mill-turn combination machining equipment, integrating robotics, automation systems, and high-precision positioning systems, and incorporating flexible and intelligent design concepts, we develop automated workstations and production lines suitable for a wide range of product specifications. This solution represents a key modern product in the metalworking industry’s journey towards automation and intelligence. It has been successfully implemented in the automotive industry, helping more manufacturers achieve intelligent manufacturing upgrades.

Conclusion

The JK20 vertical five-axis machining center combines a highly rigid machine tool structure, high-precision five-axis simultaneous, multi-process integration, and intelligent control, making it a key tool for meeting the demands of modern complex parts machining. We sincerely invite you to visit us at EMO 2025 in Hall 15, Booth B54 to experience the JK20′s superior performance and application capabilities. We look forward to providing customized solutions to support your manufacturing upgrades.

JK20 Configurations:

1. Main Configuration

2. Options
